Affordable and flexible, the MiraVista® folding door kit elevates patio openings for any home. Transform basic patio doors or exterior walls into dynamic openings, seamlessly blending indoor and outdoor living experiences.
Better By Design.
MiraVista is a kit of components that enables 1-3/4″ standard fiberglass door panels to become a customizable bi-folding door system. Whether openings are 6/8 or 8/0, an innovative sliding track with specialized components delivers seamless and simple operation.
Features and Benefits.
Bottom Gliding System
The system is designed for both new construction AND is perfect for remodels and retrofits. It doesn’t require top supports any more than a standard sliding door, because the weight of the door panels are held by the sliding track.
No Special Routing of Panels
Standard 1-3/4” Thick Fiberglass Door Panels can be used to build a MiraVista Folding Door System without any modifications or routing to the panels.
Solves imperfections in rough openings
The MiraVista knuckles can move up and down as well as side to side. This provides the ultimate ability to align doors to be square and plumb during installation and during use.
Easy Operation
To open Mira Vista, simply flip the levers to unlock the top and bottom bolts on the movable panels.
Outstanding Performance
Looks great, works better. Up to DP75 Structural and DP20 Water Performance in a 3-panel MiraVista System using Masonite VistaGrande Fiberglass Panels, when testing to ASTM Standards.
Availability and Options.
Left Hand Outswing,
Right Hand Stack Unit Shown
Right Hand Outswing,
Left Hand Stack Unit Shown
Components
- Upper Track
- Header
- Hinges
- Jambs
- Hinge Bars
- Door Panel
- Sill/Lower Track
Finish Options
Upper Track, Side Casing, and
Hinge Bar Finishes:
Sill Cap
Finishes:
Sill Deck
Finishes:
Door Unit Availability:
- Unit Width: Up to (3) 3/0 Panels
- 4 Panel Option Coming Soon!
- Max Sill Length: 115″
- Unit Height: 6/8 or 8/0
- Sill Width Options: 5-5/8″ or 7-5/8″
- Height: 6/8 or 8/0
